Installation/Removal
8.1 Installing the SIRIUS 3RA6 compact starter and AS-i mounting module
SIRIUS 3RA6 Compact Starter
62 System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
8.1.3 Installing the compact starter on a SIRIUS infeed system for 3RA6
Requirements
● The SIRIUS infeed system for 3RA6 must be correctly installed. For additional information
on installing the infeed system, please refer to "SIRIUS infeed system for 3RA6
(Page 95)".
● The c
o
mpact starter must be switched off (actuator set to
OFF position).
CAUTION
Compact starter material damage!
There is a risk of the compact starter getting damaged if it is switched on (i.e. actuator in
READY position) when you install it on the infeed system for 3RA6.
Make sure that the compact starter's actuator is set to the
OFF position before you
install the compact starter on the infeed system for 3RA6.
Procedure
Step Instructions Image
1 Attach the compact starter to the front of
the infeed system for 3RA6.
2 Push the compact starter straight onto
the infeed system for 3RA6 until you
hear it engage.
1
2
