System description
3.1 System overview
SIRIUS 3RA6 Compact Starter
14 System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
Accessories
As well as providing details of the compact starter and AS-i mounting module, this document
also describes the following accessories:
Table 3-2 Accessories for the 3RA6 compact starter
Accessories Description Chapter
Auxiliary switch block for
compact starter
Optional auxiliary switch block in
the following versions: 2 NO
contacts, 2 NC contacts or
1 NO contact + 1 NC contact
External auxiliary switch block
(Page 91)
Control kit Tool for closing the main
contacts manually by means of
the actuator
Control kit (Page 89)
Adapter for screw fastening the
compact starter
The adapters for screw
fastening enable you to install
the compact starter on a level
surface (screw fastening).
Installing the compact starter on
a level surface (screw fastening)
(Page 60)
Terminals for
"Combination Controller Type E"
The terminals conform to the
creepages and clearances
stipulated by UL 508 (Type E).
Terminal for Type E
combination motor controller,
UL 508 (Page 127)
Infeed system for 3RA6 The infeed system for 3RA6 is a
modular infeed system with an
optional PE system. The
permanent wiring means that
compact starters can be
mounted quickly and easily.
SIRIUS infeed system for 3RA6
(Page 95)
3-phase busbar The 3-phase busbar enables
several compact starters to be
fed using a single infeed
terminal.
3-phase busbar (Page 117)
8US busbar adapter The 8US busbar adapter
enables the compact starter to
be mechanically fastened and
electrically connected to a
busbar system.
8US busbar adapter
(Page 121)
Door-coupling rotary operating
mechanism
Door-coupling rotary operating
mechanisms enable compact
starters to be operated with the
control cabinet doors closed.
Door-coupling rotary operating
mechanism (Page 129)
