Siemens SIRIUS Series System Manual

Diagnostics
11.1 Compact starter diagnostics
SIRIUS 3RA6 Compact Starter
86 System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
Reversing starter display concept
Table 11-2 Display concept of the 3RA62 compact starter reversing starter
LED display Mechanical display
Compact starter status Actuator
ON I 1 ON I 2 A1/A2
B1/B2
RLT 0% TRIP
Switched off
(delivery condition)
OFF
Attempt to switch on
(direction of rotation 1 or 2)
with actuator set to OFF
OFF
Ready READY
Switched on
(direction of rotation 1)
READY
Switched on
(direction of rotation 2)
READY
Switched on following
malfunction
READY
OR OR
Overload protection function
Overload tripped READY
OR
1)
Short-circuit protection function
Short circuit tripped TRIPPED
OR
1)
Malfunction (e.g. end of service life reached)
Malfunction tripped TRIPPED
OR
1)
Ready following malfunction READY
Switched on following
malfunction
READY
1)
Depends on whether control voltage is present at the same time or whether no control voltage is present
LED: Not illuminated Mechanical display: No display
LED: Illuminated green Mechanical display: White display
