Siemens SIRIUS Series

Accessories
12.3 SIRIUS infeed system for 3RA6
SIRIUS 3RA6 Compact Starter
System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
115
Table 12-7 Spring-loaded infeed (L1, L2, L3) and PE infeed, 25/35 mm², with spring-loaded
connection technology
3RA6830-5AC
3RA6860-5AC
8WA2 806
(5.5 x 0.8 mm)

4 … 35 mm
2

6 … 25 mm
2

4 … 25 mm
2
AWG 10 to 3
Table 12-8 Screw-type infeed (25/35 mm²) (T1, T2, T3), screw-type infeed (50/70 mm²) (T1, T2, T3), 2-slot/3-slot
extension modules (T1, T2, T3) and PE tap, 6/10 mm
2
, with screw-type connection technology
3RA6813-8AB (T1, T2, T3)
3RA6812-8AB (T1, T2, T3)
3RA6822-0AB (T1, T2, T3)
3RA6823-0AB (T1, T2, T3)
3RA6870-4AB
3RA6822-0AC (T1, T2, T3)
3RA6823-0AC (T1, T2, T3)
3RA6813-8AC (T1, T2, T3)
3RA6812-8AC (T1, T2, T3)
Compact starter ... 12 A 8 ... 32 A ... 12 A 8 ... 32 A
∅ 6 mm/PZ 2
8WA2 803
(3.5 x 0.5) mm
2 … 2.5 Nm
(18 to 22 lb·in)
-

2 x (1.5 … 2.5) mm
2
2 x (2.5 … 6) mm
2
max. 1 x 10 mm
2
2 x (2.5 … 6) mm
2
max. 1 x 10 mm
2
2 x (1.5 … 6) mm
2
max. 1 x 10 mm
2
2 x (2.5 … 6) mm
2
max. 1 x 10 mm
2

- - 2 x (1.5 … 6) mm
2
2 x (2.5 … 6) mm
2

2 x (1.5 … 2.5) mm
2
2 x (2.5 … 6) mm
2
2 x (2.5 … 6) mm
2
2 x (1.5 … 6) mm
2
2 x (2.5 … 6) mm
2
AWG 2 x (16 to 14)
2 x (14 to 10)
1 x 8
2 x (14 to 10)
1 x 8
2 x (16 to 10)
1 x 8
2 x (14 to 10)
1 x 8
