Siemens SIRIUS Series System Manual

Technical data
14.1 SIRIUS 3RA6 compact starter
SIRIUS 3RA6 Compact Starter
System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
147
Order number 3RA61
3RA62
Surge suppressor Varistor (ready-integrated)
Degree of pollution 3
Safe isolation According to IEC / EN 60947-1
Control circuit to internal auxiliary circuit
Internal auxiliary/control circuit to internal auxiliary/control circuit
Internal auxiliary/control circuit to external auxiliary circuit
Main circuit to internal auxiliary circuit
Main circuit to external auxiliary circuit
V
V
V
V
V
250
250
400
400
400
Max. dimensions of direct starter
Screw-type connection technology
Spring-loaded connection technology
Max. dimensions of reversing starter
Screw-type connection technology
Spring-loaded connection technology
Depth starting from DIN rail
W x H x D
W x H x D
W x H x D
W x H x D
mm
mm
mm
mm
mm
45 x 170 x 165
45 x 191 x 165
90 x 170 x 165
90 x 191 x 165
160
Electromagnetic operating mechanism
Order number 3RA61
3RA62
Frequency range
Control voltage ranges
Working range
No-load operating frequency
OFF-delay time
ON-delay time
Where U
S
= control voltage
V
V
V
1/hour
ms
ms
DC and 50/60 Hz (+/- 5%)
24 (AC/DC)
42 to 70 (AC/DC)
110 to 240 (AC/DC)
0.7 to 1.25 x U
s
3600
Max. 70
Max. 120
Max. breakaway starting current at 24 VDC
- Up to 12 A
- 8 to 32 A
mA
mA
250
350
Holding current and holding power valid for working range 24 V
24 V, AC operation
- Up to 12 A
- 8 to 32 A
Holding current
Active power
Apparent power
cos φ
Holding current
Active power
Apparent power
cos φ
mA
W
VA
mA
W
VA
132
2.7
3.15
0.86
144
3.0
3.45
0.86
