Description of the hardware
6.1 SIRIUS 3RA61 compact starter direct starter
SIRIUS 3RA6 Compact Starter
System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
43
No. Function Marking Description
(7) Device status
• OFF
•
READY
• TRIPPED
•
OFF: Compact starter is out of service
•
OFF and eye for padlock pulled out: Compact
starter is out of service and secured against
unauthorized closing.
•
READY: Compact starter is ready
• TRIPPED: Short circuit or malfunction
(8) Connection point for auxiliary
switch block
- -
(9) Control and auxiliary conductor
terminal blocks
- -
(10) Main conductor terminal blocks - -
(11) Device status ON I
• Green: Main contacts are closed.
• Off: Main contacts are open.
(12) Control voltage A1/A2
• Green: Control voltage is present
• Off: Control voltage is not present
(13) "Short-circuit protection function"
test button
TEST I>> Press this button to test the short-circuit protection
function.
(14) Malfunction RLT 0%
• No display: Device is OK
• White display: Malfunctions detected. Device must
be replaced.
(15) "Control voltage" connection A1+, A2- -
