Siemens SIRIUS Series System Manual

Description of the hardware
6.2 SIRIUS 3RA62 compact starter reversing starter
SIRIUS 3RA6 Compact Starter
46 System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
No. Function Marking Description
(7) Device status
• OFF
•
READY
• TRIPPED
•
OFF: Compact starter is out of service
•
OFF and eye for padlock pulled out: Compact
starter is out of service and secured against
unauthorized closing.
•
READY: Compact starter is ready
• TRIPPED: Short circuit or malfunction
(8a) Connection point for auxiliary
switch block (direction of
rotation 1)
- -
(8b) Connection point for auxiliary
switch block (direction of
rotation 2)
- -
(9) Control and auxiliary conductor
terminal blocks
- -
(10) Main conductor terminal blocks - -
(11a) Device status direction of
rotation 1
ON I 1
• Green: Main contacts "direction of rotation 1"
closed.
• Off: Main contacts "direction of rotation 1" not
closed.
(11b) Device status direction of
rotation 2
ON I 2
• Green: Main contacts "direction of rotation 2"
closed.
• Off: Main contacts "direction of rotation 2" not
closed.
(12) Control voltage A1/A2
B1/B2
• Green: Control voltage is present
• Off: Control voltage is not present
(13) "Short-circuit protection function"
test button
TEST I>> Press this button to test the short-circuit protection
function.
(14) Malfunction RLT 0%
• No display: Device is OK
• White display: Malfunctions detected. Device must
be replaced.
(15) "Control voltage" connection A1+, A2/B2-, B1+ -
