● Reflect Mode Track Assembly - This track rail includes the Tension Screw and REF hole
to position one sensor.
● Direct Mode Track
Assembly - This track rail has number index holes for inserting an index
pin to position the other sensor.
Note
A pin will be inserted into the hole designated by the Number Index on the Direct Mode
track rail to position one of the sensors (see ⑩ in figure below).
Connecting
5.2 Sensor Wiring
FUP1010 IP67 Portable Flowmeter
Operating Instructions, 02/2010, A5E02951522A Revision 01
53
