SIM7000 Series_AT Command Manual_V1.03 132 2018-05-08
Mode
Max Response
Time
85 seconds
Reference Note
 AT+CIICR only activates moving scene at the status of IP START,
after operating this Command is executed, the state will be changed to
IP CONFIG.
 After module accepts the activated operation, if it is activated
successfully, module state will be changed to IP GPRSACT, and it
responds OK, otherwise it will respond ERROR.
8.2.11 AT+CIFSR Get Local IP Address
AT+CIFSR Get Local IP Address
Test Command
AT+CIFSR=?
Response
OK
Execution
Command
AT+CIFSR
Response
<IP address>
ERROR
Parameter
<IP address> A string parameter which indicates the IP address assigned
from GPRS
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
Only after PDP context is activated, local IP address can be obtained by
AT+CIFSR, otherwise it will respond ERROR. To see the status use
AT+CIPSTATUS command. Status should be:
IP GPRSACT, TCP CONNECTING, UDP CONNECTING, SERVER
LISTENING, IP STATUS,
CONNECT OK, TCP CLOSING, UDP
CLOSING, TCP CLOSED, UDP CLOSED in single-
connection mode (see
<state> parameter);
IP STATUS, IP PROCESSING in multi-connection mode (see <state>
parameter).
8.2.12 AT+CIFSREX Get Local IP Address extend
AT+CIFSREX Get Local IP Address extend
Test Command
AT+CIFSREX=?
Response
OK
Execution
Response
SIMCOM COMFIDENTIAL FILE
