SKF KFGL - Overview

Unit components
Pos. Description Chapter
1 Assembly holes 4.2.2-4.2.4
2 Lubricant reservoir 4.2.3-4.2.4
3 Fill level monitoring 4.11-4.11.4
4 Lubricant filling 4.4-4.4.3
5 Pump element 4.3-4.3.3
6 Pressure regulating valve 4.3.4
7 Electrical connection 4.5-4.5.1
8 Control port assignments 4.6-4.9
9 KFGS control unit OI Chapter 9
10 KFGL control unit OI Chapter 10
11 KFGC control unit OI Chapter 11
12 Shutdown OI Chapter 12
13 Maintenance OI Chapter 13
14 Operational and pump faults OI Chapter 14
15 Technical data OI Chapter 15
Unit components
3. Overview
KFG KFGS KFGL KFGL-MonoFlex KFGC
1
2
3
max
max
1
2
3
max
max
in
ax
Use hard grease NLGI-2 only !
KFG KFGS KFGL KFGC
Page 15
EN
OI = Operating instructions
Assembly instructions
