SKF KFGL - KFGS Display Mode

9. KFGS control unit
KFGS
9.2 KFGS display mode
Display mode can be identified by the lit-up
LED displays. The display does not flash. It is
used to query the current settings and operat-
ing parameters.
Always start the display mode by briefly press-
ing one of the two keys
.
Display mode
Step Key Display
1 The current operating status is shown
Example: Pause Timer operation
press briefly
2 Display remaining interval time for current
lubrication cycle.
Example: 1 h
3 Display pre-set total interval time
Example: 2.6 h (factory setting)
Note!
Display is in hours
4 Display pump cycle time
Example: Timer operation
5 Example: System is currently in operating
status Pause,current tCO display (timer
COntact) not possible
6 Display of the pre-set value
Example: 4 min (factory setting)
Note!
Display is in minutes
7 Display system monitoring
Display mode, Fig. 15
Page 71
EN
