15. Technical data
KFG KFGS KFGL KFGC
15. Technical data
Protective measures that must be taken for
operation according to the intended use in
machinery:
KFG; KFGS; KFGL, KFGC... 24 VDC:
"Functional Extra Low Voltage",
"Protective Extra Low Voltage"
(PELV)
Disconnect the unit for insulation and
voltage inspection according to
EN 60204-1 1992
Continuation of "Technical Data" table
Data universally applicable to KFG, KFGS; KFGL; KFGC
Description Key data/Display
Conditions for electrical connections
Rated voltage
Power consumption (load-dependent)
Power consumption (maximum)
Pump starting current (approx. 20 ms)
Max. back-up fuse
12 VDC
2.4 A
1
)
< 5 A
9 A
5 AT
2
)
3
)
24 VDC
1.25 A
1
)
< 2.5 A
4.5 A
3 AT
2
)
3
)
Fill level switch W1 NLGI 2
Fault notified by pulse
Fill level switch W1G NLGI 2
Fault notified by non-dry contact
Fill level switch W2 NLGI ≤ 1
Fault notified by capacitive proximity
switch
Electrically controlled pressure relief valve
12/24 VDC or 230 VAC
see Chapter 4.10, Page 41
Weight with full lubricant reservoir kg
2 kg version
6 kg version
10 kg version
15 kg version
20 kg version
7.5
13.5
27.0
34.5
41.5
1) Typical value at ambient temperature = 25 °C and operating pressure = 150 bar
2) Fuse per DIN 72581 T.3
3) Conductor: cross-section 1.5 mm
2,
Length ≤ 12
Page 102
