The general functional description for sin-
gle-line systems with a KFG pump unit also
applies for the design with KFGL pump control.
The LC502 control unit integrated into the
pump housing allows the following additional
configuration, monitoring and connectivity
options:
Interval time and contact time can be ad-
justed independently for pressure-moni-
tored and pressure-controlled systems
Adjustment of setting times and parame-
ters on a full dot display
Recording of remaining intervals and
remaining lubrication times
Multizone systems possible
Extensive fault monitoring/diagnosis
(diagnostics memory)
Data backup in case of voltage failure
Non-volatile memory with PIN code
protection
Connectivity for pressure switch
Fill level monitoring, lubrication cycle stop
case the level falls below minimum.
7. Functional description in single-line systems
KFGL
7.2 Functional description: (single-line
systems) with KFGL-Pump unit
Page 62
