Example of single-line system with KFG pump unit, Fig. 7
1
2 3
4
5
5
5
7
6
7. Functional description in single-line systems
KFG
max
Single-line system with KFG pump unit
1 KFG unit
2 Pump element with pressure relief valve
with integrated pressure regulating valve
3 Fill level switch
4 Main line
5 Single-line distributor
6 Pressure gauge for pressure build-up mon-
itoring
7 Pressure switch for pressure build-up
monitoring
Page 61
EN
