4. Assembly
4.1 General information
Pump units of the KFG series are an integral
component of centralized lubrication systems
used in machines and systems.
They deliver greases up to NLGI Grade 2. The
pump units differ in terms of the size of lubricant
reservoir, the lubricant filling and their control
and function monitoring. The installation of
volume-specific pump elements permits a single
unit of the KFG, KFGS or KFGL series to oper-
ate up to three independent zones.
The KFGC series is capable of operating up to
four independent zones, depending on the
task. The system can be equipped with or
without functionality to monitor pressure
build-up and reduction.
Before assembling/setting up the reservoir
unit, the packaging material and any shipping
braces (e.g., plugs) must be removed. The
packaging material must be preserved until
any discrepancies are resolved.
4.2 Setup and attachment
The pump unit should be installed in a place
protected from contamination, water splashes
and vibrations. It should, however, be easily
accessible so that all other installations can be
performed without difficulty and the device can
be filled easily. The fill level of the reservoir
must be easily visible. The unit mounting position
is vertical. Any assembly holes must be made
according to the diagram on the following
page. Design specifications and conditions of
the manufacturer and the object must be ob-
served when installing the pump unit.
A drilling jig can be ordered
(order number 951-130-115).
During assembly and especially when drilling,
always pay attention to the following:
Existing supply lines must not be dam-
aged by assembly work.
Other units must not be damaged by
assembly work.
The product must not be installed within
range of moving parts.
The product must be installed at an ade-
quate distance from sources of heat.
Maintain safety clearances and comply
with local regulations for assembly and
accident prevention.
KFG KFGS KFGL KFGC
Page 16
EN
Assembly instructions
