OVERVIEW
3. OVERVIEW
3.1 PLANTER OVERVIEW
1- Fertilizer hopper.
2- Suction system fan.
3- Insecticide Micro granulator / Helicide Micro
granulator drive.
4- Insecticide Micro granulator / Helicide Micro
granulator hopper.
5- Metering Unit.
6- Air reservoir.
7- Frame.
8- Supporting leg.
9- Furrow’s residue rotary cleaner.
10- Drive wheel.
11- Gearbox.
12- Deector.
13- PTO.
14- Fertilizer unit.
15- Level indicator.
16- Fertilizer hopper’s drive.
17- Hydraulic connections.
18- Track marker.
