Sola PROSEM K BASIC Series - Fertilising Equipment (Optional); Fertilizers on Planting Element (Optional)

ADJUSTMENTS
10
6.18 FERTILISING EQUIPMENT (OPTIONAL)
6.18.4 FERTILIZERS ON PLANTING ELEMENT
(OPTIONAL)
- DOUBLE FERILIZER DISC ON ELEMENT SUPPORT
Fig. 6.xx
- FERTILIZER COULTER ON ELEMENT SUPPORT
Fig. 6.yy
To adjust position:
- HEIGHT
Operate the nuts and screws to modify the working depth
(1, Fig. 6.AA).
- PRESSURE
Operate the nut to modify the pressure of the unit (2, Fig.
6.AA).
1
Fig. 6.AA
2
