OVERVIEW
3.7.4 VARIANT
This frame allows to modify the spacing between every metering unit. Possible adjustments can
be found in section 6.5.4 VARIANT MACHINE.
There are two versions of this model:
- Variant simple telescopic (Fig. 3.20)
- Variant double telescopic (Fig. 3.21)
3.7.5 VARIANT IDRA
Frame VARIANT IDRA allows to modify the spacing between every unit. The frame’s working wi-
dth is variable. To adjust spacing between the metering boxes, see section 6.5.5 VARIANT IDRA
MACHINE (Fig. 3.22).
