76
1
2
3
Fig. 6.87
ADJUSTMENTS
WHEEL’S BEARING ANGLE IN THE TABLE IS SHOWN IN RELATION TO THE FORWARD DIRECTION
(FIG. 6.85 AND 6.86).
6.11.2 FURROW-COVERER – PROSEM P
Closing the furrows created by the metering unit PROSEM P is performed by the seed-covering
device and the press wheel FARMFLEX
There are two types of seed-covering device depending on the model of PROSEM P:
- SHORT ARM, in PROSEM P WITH HIGH SHARE
- LONG ARM, in PROSEM P
ONLY THE SEED-COVERING DEVICES ARE ADJUSTABLE. THE WHEEL FARMLEX ONLY PRESSES THE
TERRAIN WHERE THE SEED HAS BEEN PLACED.
6.11.2.1 REGULACIÓN CUBRESEMILLAS PROSEM P BOTA ALTA
PROSEM P HIGH SHARE is provided
has two seed-covering devices, one
on each side of the metering unit.
Each seed-covering device consists
of one arm (2, Fig. 6.87) and a cove-
ring device (3, Fig. 6.87).
The seed-covering can be adjus-
ted by modifying its height above
terrain. To perform the adjustment
follow these steps:
1- Loosen the screw (1, Fig. 6.87).
2- Shift the lever (2, Fig. 6.87) to the
desired position.
3- Fix the seed-covering arm by tightening the screw (1, Fig. 6.87).
W
T
Fig. 6.85
Forward direction
ß
Fig. 6.86
Forward direction
- ß
