OVERVIEW
3.7.6 FOLDING FRAME
This type of frame has a CENTRAL
BODY (1, Fig. 3.23) and two FOL-
DING PARTS (2, Fig. 3.23).
The CENTRAL BODY can be:
- FIXED
- VARIANT MANUAL
- TELESCOPIC
- VARIANT IDRA
- OMNIA
FOLDING PARTS can be:
- FIXED
- VARIANT MANUAL
To adjust the row spacing, see section 6.5.6 FOLDING MACHINE.
Fig. 3.23
2
1
