Fig. 6.95
3
1
2
Fig. 6.94
ADJUSTMENTS
6.12.4 ADJUSTING THE FURROW’S RESIDUE ROTARY CLEANER IN PROSEM K
METERING UNITS (OPTIONAL)
The furrow’s residue rotary cleaners remove the residues of the sowing row. They need to work
always supercially and can be adjusted in HEIGHT.
To adjust the working height of the furrow’s residue rotary cleaner, follow these steps:
1- Loosen the securing lever (1, Fig. 6.95)
2- Turn the knob (2, Fig. 6.95) until reaching the desired working height. To adjust the hei-
ght, use the graduated scale (3, Fig. 6.95).
3- Fix the position using the lever (1, Fig. 6.95).
PERFORM THIS OPERATION ALWAYS WHEN THE PLANTER IS IN A RAISED POSITION.
