121
1
Fig. 9.23
1
2
Fig. 9.25
A
Fig. 9.24
1
2
MAINTENANCE
IMPORTANT: ALWAYS KEEP THE AIR RESERVOIR CLEAN (1, Fig. 9.23) AND PERIODICALLY CHECK
IT IS IN GOOD CONDITION.
IN PLANTER’S MODELS EQUIPPED WITH FOLDING FRAME, CLEAN THE MAIN AIR RESERVOIR (1,
FIG. 9.24) AND THE AIR RESERVOIRS OF THE FOLDING PARTS (2, FIG. 212). PERFORM THIS OPERA-
TION ONLY WHEN THE PLANTER IS OPEN (FIG. 9.24).
To clean the air reservoir, follow these steps:
1- Remove the screws and nuts from the two laterals of the air
reservoir (1, Fig. 9.25) and, next, remove the lids.
2- Use compressed air to blow air into the air reservoir.
3- Place the lids, screws and nuts back.
CHECK THAT THE LIDS ARE PROPERLY PLACED. IF NECESSARY, USE SILICONE TO
SEAL THE LID’S SIDES WHICH ARE IN CONTACT WITH THE AIR RESERVOIR.
