29
Fig. 5.6
Fig. 5.5
Fig. 5.7
Fig. 5.8
STARTING
3- Adjust the length of the tractor’s tensioning arm
until the machine is parallel to the ground. For
this purpose, use the level placed on the tripod’s
side.
4- Connect the following plugs from the hydrau-
lic system to the tractor’s hydraulic connections
(Fig. 5.5):
-
TRACK MARKERS
-
SUCTION FAN (in models provided with hy-
draulic fan).
- FRAME, in models: TELESCOPIC, VARIANT,
IDRA AND FOLDING.
-
FRONTAL FRAME (OPTIONAL EQUIPAMENT).
IN MACHINES WITH MECHANICAL FAN, COUPLE
BOTH THE TRACTOR’S PTO’S SHAFT AND THE
PLANTER’S PTO SHAFT TO THE PTO SHAFT (SEE
SECTION 5.2 Connecting and adapting the PTO
shaft)
5- Before starting to work with the machine, raise the
machine’s supporting legs (Fig. 5.7).
BEFORE RUNNING WITH THE MACHINE, PLEASE
CHECK THAT IT IS CORRECTLY COUPLED TO THE
TRACTOR.
TO UNCOUPLE THE MACHINE FROM THE TRACTOR,
PERFORM THE FORMER STEPS IN THE REVERSE OR-
DER.
