ADJUSTMENTS
THE SUPPORT WHERE THE TURBO DISC OPENER IS ASSEMBLED (1, Fig. 6.103) NEEDS TO WORK
WITHOUT PENETRATING THE EARTH. FOR THIS PURPOSE, IT NEEDS TO BE ADJUSTED SO THAT
IT WORKS IN A RAISED POSITION OF AT LEAST 2 CENTIMETRES (APROXIMATELY) ABOVE THE
GROUND (Fig. 6.103).
THE TURBO DISC OPENER NEEDS TO PENETRATE THE EARTH BETWEEN 1 AND 2 CENTIMETRES IN
RELATION TO THE PLANTING DEPTH (Fig. 6.104). SEE SECTION 6.8 PLANTING DEPTH TO CALCU-
LATE THE WORKING DEPTH OF THE DISC OPENER’S.
T
W
T
1 or 2 cm
TURBO DISC OPENER’S WORKING DEPTH
Ground level
Fig. 6.104
Fig. 6.103
Minimum
depth
Maximum
depth
1
2 cm
(mínimum)
Maximum
Ground Level
Minimum
Ground Level
