Chapter 1 - Welcome
5. Position one person on either side of the SolarCity H6 inverter top section and lift it
straight up until it is flush against the mounting bracket and can be lowered into position.
6. Lower the inverter top section into position in the reverse of what is shown in
Figure 10-1
while verifying all of the following:
- The inverter top section is engaging with both of the tabs on the mounting bracket.
- The three screw posts extending from the bottom of the inverter top section are going
through the proper holes into the wiring box.
- Both sets of wires extending from the bottom of the inverter top section are going
through the proper holes into the wiring box.
7. Using a 10mm wrench, secure the three nuts (2) holding the top section of the inverter to
the wiring box section. Torque to 21 foot-pounds (28Nm).
8. Connect the wires (1) to the spring-clamp connectors, following the color codes and
instructions printed on the wiring box printed circuit board (PCB). See
Figure 10-2
.
WARNING: THE SOLARCITY H6 INVERTER WEIGHS 62LBS (28KG). ALL
LIFTING MUST BE PERFORMED BY TWO PEOPLE, PER OSHA
REQUIREMENTS. ALWAYS LIFT WITH YOUR LEGS AND FOLLOW ALL OTHER
APPLICABLE BEST PRACTICES FOR AVOIDING INJURY WHEN LIFTING
HEAVY LOADS.
WARNING: KEEP LEGS, FEET, AND OTHER BODY AREAS AWAY FROM THE
AREA DIRECTLY UNDERNEATH THE INVERTER UNTIL IT IS SECURELY
INSTALLED ON THE MOUNTING BRACKET AND YOU HAVE VERIFIED THAT
THE MOUNTING BRACKET IS CAPABLE OF SUPPORTING THE FULL WEIGHT
OF THE INVERTER WITH NO DEFORMATION OR MOVEMENT.
SHOCK HAZARD: VERIFY THAT ALL WIRES EXTENDING FROM THE
BOTTOM OF THE INVETER TOP SECTION ENTER THE WIRING BOX. ONE OR
MORE WIRE(S) LEFT EXPOSED BETWEEN THE TOP SECTION AND WIRING
BOX CAN CAUSE A POTENTIALLY FATAL ELECTROCUTION HAZARD.
WARNING: FAILURE TO PROPERLY CONNECT ALL WIRES TO THE CORRECT
SPRING-CLAMP CONNECTORS COULD CAUSE A FIRE OR OTHER
HAZARDOUS CONDITION.
CAUTION: FAILURE TO PROPERLY CONNECT ALL WIRES TO THE CORRECT
SPRING-CLAMP CONENCTORS COULD DAMAGE THE SOLARCITY H6
INVERTER AND WILL VOID THE WARRANTY.
