5 - Electrical

Connections

This section provides instructions for making the electrical connections to the SolarCity H6

inverter.

WARNING: READ ALL OF THESE INSTRUCTIONS, CAUTIONS, AND

WARNINGS FOR THE H6 INVERTER AND ASSOCIATED PV ARRAY

DOCUMENTATION.

SHOCK HAZARD: POWER MAY BE FED FROM MORE THAN ONE SOURCE

AND/OR VIA MORE THAN ONE LIVE CIRCUIT. PLEASE NOTE THAT ALL DC

AND AC CONNECTORS MAY CARRY CURRENT EVEN WITHOUT

CONNECTED WIRES.

SHOCK HAZARD: ENSURE THAT NO LIVE VOLTAGES ARE PRESENT ON PV

INPUT AND AC OUTPUT CIRCUITS, AND VERIFY THAT THE DC

DISCONNECT, AC DISCONNECT, AND DEDICATED AC BRANCH CIRCUIT

BREAKER ARE IN THE “OFF” POSITION BEFORE INSTALLING THE

SOLARCITY H6 INVERTER.

SHOCK HAZARD: PV SOLAR ARRAYS PRODUCE HAZARDOUS VOLTAGES

AND CURRENTS WHEN EXPOSED TO LIGHT WHICH CAN CREATE AN

ELECTRICAL SHOCK HAZARD.

WARNING: THE METHODS USED TO INSTALL AND WIRE THE SOLARCITY H6

INVERTER IN THE UNITED STATES MUST COMPLY WITH ALL US NATIONAL

ELECTRIC CODE REQUIREMENTS (NEC) AND LOCAL AHJ INSPECTOR

REQUIREMENTS. IN CANADA, THE INSTALLATION AND WIRING METHODS

USED MUST COMPLY WITH PARTS I AND II OF THE CANADIAN ELECTRIC

CODE, AS WELL AS ALL LOCAL AHJ INSPECTOR REQUIREMENTS. THE

INSTALLER IS RESPONSIBLE FOR ALL SYSTEM GROUNDING REQUIRED BY

PART I OF THE CANADIAN ELECTRICAL CODE.
