H6 Hybrid Inverter - Installation & Operation Guide
76
Copyright 2017 SolarCity Corporation. All rights reserved.
6.1.2 - LCD Display
As shown in
Figure 6-1
, the SolarCity H6 inverter includes a two (2) line LCD display with 16
characters per line. In this display:
• The first row names the currently-displayed menu.
• The second row displays the menu/parameter elements.
6.1.3 - Push Buttons
As shown in
Figure 6-1
, the SolarCity H6 inverter includes the following four (4) push buttons:
For example, to change the grid voltage:
1. Press the [UP] and/or [DOWN] buttons in the main menu to highlight Grid Voltage, and
then press [ENTER] to select that menu.
2. Use the [UP] and/or [DOWN] buttons to select Grid Voltage Level1.
3. Press [ENTER] to select this option.
4. Use the [UP] and/or [DOWN] buttons to select Yes.
5. Press [ENTER] to confirm the change.
Label Menu Function Parameter Function
ESC Exits the current menu. Cancels setting the current value.
UP Move upward in a menu. Increase the current value.
DOWN Move downward in a menu. Decrease the current value.
ENTER Select the indicated menu entry or
open a configurable parameter for
editing, as appropriate. Can also be
used to pause/resume menu
scrolling.
Save the value with its current setting
