H6 Hybrid Inverter - Installation & Operation Guide

8.2 - Powering Off the Inverter

To power off the SolarCity H6 inverter:

1. Turn the DC Disconnect Switch to the OFF position.

2. Place the padlock on the DC Disconnect Switch, if needed.

3. Move the breaker(s) in the backup load panel to the OFF (open) position.

4. At the main electrical panel, turn the dedicated back-feed circuit breaker and/or

external AC disconnect to the OFF (open) position.

8.3 - Bypassing the Inverter

If the SolarCity H6 inverter is damaged and is not functioning, then the AC Bypass Switch can

be turned to the BYP position. This will directly connect the protected home loads to the AC

grid, bypassing the inverter. SolarCity recommends that the homeowner do this first and

then report the issue to SolarCity Customer Service.

8.4 - Opening /Closing the Inverter

See

“Wiring Box Cover” on page 59

SHOCK HAZARD: FAILURE TO PLACE THE PADLOCK ON THE DC

DISCONNECT SWITCH MAY RESULT IN THIS SWITCH BEING TURNED ON,

WHICH CAN FEED CURRENT INTO THE PROTECTED HOME LOADS AND

LEAD TO DEATH OR SERIOUS INJURY FROM ELECTROCUTION.
