H6 Hybrid Inverter - Installation & Operation Guide
112
Copyright 2017 SolarCity Corporation. All rights reserved.
9. Replace the wiring box cover as described in
“Refit Wiring Box Cover” on page 60
.
10. Power on the inverter as described in
“Powering On the Inverter” on page 85
.
Figure 10-2: Wires from inverter top section to wiring box
PV1-
PV1+
PV2-
PV2+
BAT+
BAT-
GND
BL1
BN
BL2
L1
N
L2
RIBBON
CABLE
