4 - Installation
This section covers installing the SolarCity H6 inverter, including:
• Installing the Inverter Mounting Bracket on the wall.
• Hanging the inverter on the wall.
SHOCK HAZARD: ENSURE THAT NO LIVE VOLTAGES ARE PRESENT ON PV
INPUT AND AC OUTPUT CIRCUITS, AND VERIFY THAT THE DC
DISCONNECT, AC DISCONNECT, AND DEDICATED AC BRANCH CIRCUIT
BREAKER ARE IN THE “OFF” POSITION BEFORE INSTALLING THE
SOLARCITY H6 INVERTER.
WARNING: READ THIS ENTIRE GUIDE AND ALL INSTRUCTIONS, CAUTIONS,
AND WARNINGS FOR THE SOLARCITY H6 INVERTER AND ALL
INSTALLATION COMPONENTS, PAYING PARTICULAR ATTENTION TO
SHOCK HAZARD AND WRANING CALLOUTS.
WARNING: INSTALLATION AND COMMISSIONING MUST BE PERFORMED BY
A LICENSED ELECTRICIAN IN ACCORDANCE WITH LOCAL, STATE, AND
NATIONAL ELECTRICAL CODE ANSI/NFPA 70 REQUIREMENTS.
WARNING: THE METHODS USED TO INSTALL AND WIRE THE SOLARCITY H6
INVERTER IN THE UNITED STATES MUST COMPLY WITH ALL US NATIONAL
ELECTRIC CODE REQUIREMENTS (NEC) AND LOCAL AHJ INSPECTOR
REQUIREMENTS. IN CANADA, THE INSTALLATION AND WIRING METHODS
USED MUST COMPLY WITH PARTS I AND II OF THE CANADIAN ELECTRIC
CODE, AS WELL AS ALL LOCAL AHJ INSPECTOR REQUIREMENTS. THE
INSTALLER IS RESPONSIBLE FOR ALL SYSTEM GROUNDING REQUIRED BY
PART I OF THE CANADIAN ELECTRICAL CODE.
WARNING: ALL SERVICING INSTRUCTIONS ARE INTENDED FOR USE BY
QUALIFIED PERSONNEL ONLY. TO REDUCE THE RISK OF ELECTRIC
SHOCK, REFER ALL SERVICING TO FACTORY QUALIFIED SERVICE
PERSONNEL. THE SOLARCITY H6 INVERTER CONTAINS NO USER-
SERVICEABLE PARTS.
