H6 Hybrid Inverter - Installation & Operation Guide
24
Copyright 2017 SolarCity Corporation. All rights reserved.
3.3.2 - 24” Wall
When installing the Inverter Mounting Bracket on a wall with 24” stud spacing:
• Use one (1) in the upper middle into the stud.
• Use one (1) screw in the lower middle into the stud.
• Use one (1) screw in either off-center lower hole. Use a suitable wall anchor if needed.
Mount the Inverter Mounting Bracket as described in
“Installing the Inverter Mounting
Bracket” on page 51
.
3.3.3 - Single Pillar
When installing the Inverter Mounting Bracket on a wall with a single pillar:
• Use one (1) screw in the upper left with a suitable wall anchor.
• Use one (1) screw in the upper middle into the pillar.
• Use one (1) screw in the upper right with a suitable wall anchor.
• Use one (1) screw in the lower middle into the pillar.
Mount the Inverter Mounting Bracket as described in
“Installing the Inverter Mounting
Bracket” on page 51
.
3.3.4 - Masonry or Concrete Walls
When installing the Inverter Mounting Bracket on a concrete or masonry wall:
• Use one (1) screw in the upper left with a suitable wall anchor.
• Use one (1) screw in the upper right with a suitable wall anchor.
• Use one (1) or two (2) screw(s) in the lower center or lower left/right with a suitable wall
anchor or anchors.
CAUTION: THE WALL ANCHOR(S) ARE TO BE USED ONLY TO STEADY THE
INVERTER MOUNTING BRACKET AGAINST THE WALL. THEY ARE NOT
INTENDED TO BE WEIGHT BEARING.
CAUTION: THE WALL ANCHOR(S) ARE TO BE USED ONLY TO STEADY THE
INVERTER MOUNTING BRACKET AGAINST THE WALL. THEY ARE NOT
INTENDED TO BE WEIGHT BEARING.
