10.5 - Replacing Internal Components
This section describes how to remove and replace fuses, fan, and 9V battery inside the
SolarCity H6 inverter wiring box. Figure 10-3 displays these components for units that have a
separate PLC Transmitter box and for units with an integrated PLC Transmitter.
Figure 10-3: Internal components (with separate PLC, top; with integrated PLC, bottom)
2
3 4
5
1
4
7
6
2
3 4
5
1
4
7
6
