H6 Hybrid Inverter - Installation & Operation Guide
52
Copyright 2017 SolarCity Corporation. All rights reserved.
4.3.2 - Hanging the Inverter
Refer to the numbered callouts in
Figure 4-2
. To hang the SolarCity H6 inverter:
1. With at least one person on either side of the inverter, grasp it by the handles (1).
2. Lift the inverter up until the mounting slots on the back of the inverter are just above the
level of the tabs (2) on the Inverter Mounting Bracket.
3. Move the inverter horizontally back until it is flush against the Inverter Mounting Bracket.
4. Slide the inverter directly down onto the mounting tabs, and ensure that both the top
section and wiring box are fully engaging with all of the tabs.
5. Verify that the Inverter Mounting Bracket tabs are fully engaged on the back side of the
wiring box.
6. Gently press on the inverter to verify that it is securely seated and cannot displace
vertically or horizontally.
7. Gradually release the inverter, taking care to ensure that the Inverter Mounting Bracket is
taking the weight with no movement or deformation.
WARNING: THE SOLARCITY H6 INVERTER WEIGHS 62LBS (28KG). ALL
LIFTING MUST BE PERFORMED BY TWO PEOPLE. ALWAYS LIFT WITH YOUR
LEGS AND FOLLOW ALL OTHER APPLICABLE BEST PRACTICES FOR
AVOIDING INJURY WHEN LIFTING HEAVY LOADS.
WARNING: KEEP LEGS, FEET, AND OTHER BODY AREAS AWAY FROM THE
AREA DIRECTLY UNDERNEATH THE INVERTER UNTIL IT IS SECURELY
INSTALLED ON THE INVERTER MOUNTING BRACKET AND YOU HAVE
VERIFIED THAT THE INVERTER MOUNTING BRACKET IS CAPABLE OF
SUPPORTING THE FULL WEIGHT OF THE INVERTER WITH NO
DEFORMATION OR MOVEMENT.
