H6 Hybrid Inverter - Installation & Operation Guide
50
Copyright 2017 SolarCity Corporation. All rights reserved.
Seal all unused conduit opening with the plastic conduit plugs included with the inverter.
4.3 - Mounting the Inverter
Refer to the following instructions before installing the SolarCity H6 inverter:
•
“Qualification of Skilled Workers” on page 5
•
“Safety Instructions” on page 11
•
“Overview” on page 17
•
“Selecting a Location” on page 48
The general installation procedure consists of:
1. Installing the Inverter Mounting Bracket on the wall. See
“Installing the Inverter Mounting
Bracket” on page 51
.
2. Hanging the SolarCity H6 inverter on the Inverter Mounting Bracket. See
“Hanging the
Inverter” on page 52
.
WARNING: THE SOLARCITY H6 INVERTER WEIGHS 62LBS (28KG). ALL
LIFTING MUST BE PERFORMED BY TWO PEOPLE. ALWAYS LIFT WITH YOUR
LEGS AND FOLLOW ALL OTHER APPLICABLE BEST PRACTICES FOR
AVOIDING INJURY WHEN LIFTING HEAVY LOADS.
Note: For optimal structural integrity, the SolarCity H6 inverter should be
inclined at no more than 5 degrees relative to the wall.
