H6 Hybrid Inverter - Installation & Operation Guide
40
Copyright 2017 SolarCity Corporation. All rights reserved.
overloading. Refer to
“Intended Uses” on page 103
. The SolarCity H6 inverter is rated to a
continuous maximum of 3kW (25A@120V)/single-phase or 6kW (25A@240V) for split phase.
IEEE 1547 and ANSI regulations specify the following default operating ranges
• Voltage range for 120V: 105V (-12%) to 132V (+10%)
• Frequency range for 60Hz: 59.3Hz to 60.5Hz
Please see
Figure 1-2
for general wiring options.
Note: The SolarCity H6 inverter transitions from an on-grid inverter to an
off-grid (or backup) situation if utility grid power is lost. This transition
may take one (1) to two (2) second(s) and may cause some inconveniences,
such as the need to reset appliance clocks or restart some appliances.
Consider adding an additional Uninterruptible Power Supply (UPS) for
loads such as computers that can lose data or other important
functionality when power is lost.
Note: In night mode, the SolarCity H6 inverter may take up to eight (8)
seconds to transition from on-grid to off-grid.
CAUTION: ALL WIRING MUST BE SIZED TO AT LEAST 167
°
F (75
°
C) PER NEC
TABLE 310.15(B)(16) AND RATED TO AT LEAST 194
°
F (90
°
C).
Note: NEC 310.15 specifies the wiring AWG to use.
Note: These values are subject to change. Please refer to the SolarCity H6
Inverter Datasheet for updated values.
