5 Operation
Lifting
7071_003-104
1
2
Fork extension
– Slide the fork extension (1) (special equip-
ment) onto the fork arms and secure it with
the socket pins (2).
WARNING
The fork extension affects the stability of the forklift
truck.
Theweightsallowedaccordingtothecapacityra-
ting plate must thus be reduced in relation to the
actual load distance; see ⇒ Chapter "Prior to taking
up a load", P. 5-103.
Operation with reversible forks
7090_862-013
Normal operation
Like a normal fork, the reversible fork arms
(special equipment) can be lifted and tilted
with the mast.
100 171673 [EN]
