Maintenance 6
Maintenance as required
– Measure the tread depth at all four wheels.
– Remove any foreign matter that may have
become lodged in the tyre tread.
Checking wheel fastenings
7071_003-046
1
3
2
– Check the wheel fastening bolts (3) for tight-
ness and re-tighten as necessary, for tight-
ening torque values see ⇒ Chapter "Mainte-
nance data table", P. 6-186.
7071_003-125
4
1
2
3
0
Checking adjustment of the foot-
brake
NOTE
Readjust the brake cable only if it has become
elongated.
– Remove the floorplate, see ⇒ Chap-
ter "Installing and removing the floor-
plate", P. 6-194
– Check whether the clearance between the
linkage bar (lever) (3) and the adjusting
screw (4) is 0 mm.
CAUTION
Risk of damage to components.
The adjusting screw (4) is set at the factory and may
not be readjusted.
– Check the clearance between the fork clevis
(2) and linkage bar (lever) (3).
Set value: 0–1 mm
171673 [EN] 209
