Overviews 4
Operating and display elements
1
2
3
4
5
7071_003-004
1 Forward travel display
2 Right flasher display
3 Reverse travel display
4 Message display
5 Left flasher display
Direction of travel/flasher/fault multi-
function display
The direction of travel/flasher/fault multi-func-
tion display is used to display the direction of
travel. In addition, the flasher is used to indi-
cate that messages are shown on the display
and operating unit.
7311_003-056
1
2
1 Travel direction switch
2 Direction indicator switch
Mini-console
The mini console is located on the steering
column below the steering wheel.
NOTE
Switch (1) is not assigned in trucks with the
travel direction switch on the "lift-lower" ope-
rating lever.
171673 [EN] 47
