Operation 5
Start-up
7311_003-048
1
2
3
– Slowly guide the belt tongue (2) back to the
retractor (3) by hand.
NOTE
Do not allow the belt to retract too quickly.
The automatic blocking mechanism may be
triggered if the belt tongue strikes the housing.
It will then no longer be possible to pull the belt
out again with the usual force.
– Using increased force, pull the belt out of the
retractor approx. 10-15 mm, thus releasing
the blocking mechanism.
– Allow the belt to retract slowly.
– Prevent the belt becoming dirty (for exam-
ple, by covering).
Malfunctions due to cold
– Thaw a frozen buckle or retractor and dry
the parts to prevent repeated freezing.
CAUTION
Risk of damage to components!
When thawing, do not subject the buckle or retrac-
tor to excessive heat.
– The temperature of the warm air should not ex-
ceed 60°C when thawing.
7081_003-011
1
2
Checking function of brake system
DANGER
Risk of accident!
Do not put forklift trucks with a defective brake sys-
tem into service.
Checking foot brake
– Check pedal clearance.
The brake must have sufficient distance from
the pressure point to the pedal stop.
– Accelerate empty truck in a clear area.
– Press the brake pedal (1) firmly.
Check brake for noticeable delay.
171673 [EN] 73
