1 Foreword
Information about documentation
6210_001-031
4
2
3
1
Definition of directions
The directions forwards (1), backwards (3),
right (2), left (4) give the installation locations
of parts as seen from the driving position; the
load is at the front.
6210_001-009
Sample graphics
This documentation explains the (usually se-
quential) sequence of certain functions or
operations. Schematic diagrams of a coun-
terbalance truck are used to illustrate these
sequences.
NOTE
These schematic diagrams are not represen-
tative of the constructed state of the docu-
mented industrial truck. They serve only to
illustrate the sequences.
6 171673 [EN]
