Maintenance 6
General maintenance information
Unit
Operating materials
Specification
Dimension
- Mast bearing screws Torque wrench M16x80 10.9: 290 Nm
Load chains
Chain spray
ID no. 141001
ID no. 156428
As required
- Setting Distance from the
support roller under
the inside mast to the
top edge: 15 mm
Steering axle
-Axlestubnuts Torque wrench 310 Nm
- Wheel hub fastening
Torque wrench 470 Nm
Cooling system Coolant/water G12 plus
TL-VW 774 F
Approx. 15.5 l
LPG cylinder LPG
DIN 51622
EN 589
11 kg
Engine Engine oil VW 50700
With filter change
approx. 6.4 l
- Ignition system
Spark plugs NGK IZKR 7B
VW no.:
101.905.606.A
Gap between
electrodes: 1.0 ±
0.1 mm
Tightening torque:
20 Nm
Air filter
-Dryairfilter
Filter rinsing solution
-
As required
171673 [EN] 187
