Maintenance 6
1000-hour maintenance/annual maintenance
NOTE
Change oil only when engine is at operating
temperature.
– Open the floor opening in the chassis.
7094_121-005
1
2
– Place a suitable collection vessel under the
oil drain plug (1).
– Unscrew the oil drain plug (1) and allow the
oil to drain out completely.
ENVIRONMENT NOTE
Disposeofusedoilaccordingtoapplicable
regulations.
– Renew the sealing ring (2).
– Tighten the drain plug with a torque of
30 Nm.
4
5
6
7081_003-032
3
– Place a suitable collection vessel under the
oil drain plug (3).
– Unscrew the oil drain plug (3) and allow the
oil to drain out completely.
– Renew the sealing ring .
– Tighten the drain plug
– Unscrew the oil filter (4) cover.
ENVIRONMENT NOTE
Dispose of used oil and oil filter insert accor-
ding to applicable regulations.
– Renew the oil filter insert(6).
– Renew the O-rings (5).
– Screw the oil filter cover back on (4) hand-
tight.
171673 [EN] 225
