S CLASS™ cutter User’s Manual
Detailed Operation 4-7
Language:
This submenu is used to set or modify the dialogue language on the touch screen. When
the machine is new, it asks the user to choose a language. If this setting was set to the
wrong language, it can be changed with this option.
The information on the touch screen can be displayed in English, French, German, Spanish,
Italian, Polish or Dutch.
Press the button, then use or to set to the desired language.
Press
,
to confirm or to cancel.
The default language is chosen when the cutter is switched on for the first time.
Panel Units:
The setting of these options determines whether the speed and size values are displayed in
the metric measure system or ENG/US measure system.
Press the button, then use or to set to the desired measure system.
Press
,
to confirm or to cancel.
The panel units are chosen when the cutter is switched on for the first time.
Recut Offset:
The recut offset submenu is used to set or modify the distances between the jobs when
making multiple recuts.
Press the button, then use or to set to the desired value.
Press
,
to confirm or to cancel.
The default value is 40mm.
Cut off margin:
The cut off margin submenu is used to set or modify the distance the cutter will feed before
it will cut off the job when action ‘cut off’ is used from the touch screen.
Press the button, then use or to set to the desired value.
Press
,
to confirm or to cancel.
The default value is 10mm.
NOTE: The recut offset should be bigger than the cut-off margin if both parameters are
used in the same job. For OPOS jobs using the cut-off command it is required that the recut
offset is at least 30mm bigger than the cut-off margin.
