S CLASS™ cutter User’s Manual
Specifications 6-5
6.2.4 Interface
Communication
USB and standard asynchronous RS-232-C interface
USB
I/O Port connector USB series “B” receptacle (female plug)
Mating connector USB series “B” plug (male plug)
Version 1.1
RS-232
I/O Port connector DB-9P
Mating connector DB-9S
Byte format 8 data bits, 2 stop bits, no parity
Baud rate 57600, 38400, 19200, 9600, 4800, 2400 bps
TABLE 6-4
6-4 S CLASS™ INTERFACE SPECIFICATIONS
6.2.5 Firmware
Language
DM/PL, HP-GL (758x emulation), HP-GL/2
Supported character sets
Standard ASCII
Supported fonts
Sans serif (single stroke & medium)
ROM-based plots
Confidence plot, DIN plot
TABLE 6-5
6-5 S CLASS™ FIRMWARE
