S CLASS™ cutter User’s Manual
Specifications 6-4
6.2.3 Knife, pen and pouncing tool
The S CLASS™ cutter comes equipped with all the tools necessary to start working
immediately.
Some tools are pre-installed, while others are packaged in separate boxes.
Below is a table that specifies which tools were delivered with the cutter. Please make sure
that all tools were included with the cutter.
Medium
Standard drag knife
Standard vinyl up to 0.25mm
(0.03”) thick
2 1
Sandblast drag knife (requires sandblast
knife holder)
Sandblast and materials thicker
than 0.25mm (0.03”)
x x
Standard tangential knife
Standard vinyl up to 0.25mm
(0.03”) thick
x
2
Sandblast tangential knife (requires
special sandblast nose piece)
Sandblast and materials thicker
than 0.25mm (0.03”)
x
1
Fiber type plotter type pen
Paper 1
x
Ball point pen (requires ballpoint
penholder)
Paper
x
1
Pouncing pin
Paper
1 1
Razor blade for cut sheet
Standard vinyl up to 0.25mm
(0.03”) thick
2 2
TABLE 6-3
6-3 S CLASS™ TOOLS
To order replacement knives, pens and/or pouncing tools, contact your local Summa dealer,
quoting the part numbers listed in table 6-8.
The S CLASS™ cutters will only perform according to specifications if a genuine Summa
knife, pen or pouncing tool is installed. Do not replace the standard knife, pen or pouncing
tool with products from other manufacturers.
