Detailed Operation 4-1
4 Detailed Operation
4.1 Introduction
This section is a detailed list of all parameters that can be changed and tests that can be
initiated from the touch screen.
Section 1 and 2 of this manual describe in detail the most commonly used touch screen
manipulation.
This section may be used as a reference for locating a certain parameter setting or test. The
less frequently used parameters are also explained in this section.
4.2 Action Menu
FIG 4-1
4-1 ACTION MENU
Most of the explanation of this menu is covered in previous sections.
Set Origin: Used to change the origin of the tool carriage on a loaded piece of media.
After this button is pressed, arrow keys will appear to allow the user to go to the new origin.
Load: The loading procedure is explained in section 1.5.4.
Reset: Used to interrupt an ongoing job.
Media alignment: Starts the loading procedure for contour cutting; see section 3.3.6.
Replot: Each job is stored in the cutter’s memory until a new job is sent. Pressing replot
allows the job to be replotted. After this button is pressed, the user may choose the number
of replots. The replot button does not work if there is no job in the memory, or if the
previous job was larger than the cutter’s memory.
Cut off: Moves the media till after the last cut vector and cuts off from the roll with the cut
off knife.
