S CLASS™ cutter User’s Manual
Detailed Operation 4-8
Roll up media:
The roll up media submenu is used to choose when the cutter will start the automatic roll
up. There are 3 possible settings. Off, after job and after AUTO-panel.
Off disables the roll-up system. After job rolls up the media after the job, regardless the
number of panels the job had. After AUTO panel roll up the media each time a panel is cut.
The size of the panel can be set in the Panels menu or is 100cm when paneling is set to off.
Press the button, then use or to set to the desired value.
Press
,
to confirm or to cancel.
The default value is after AUTO-panel.
Autoload:
The Autoload option enables the user to the change the vinyl unroll procedure. When
autoload is on, the cutter will automatically unroll the vinyl when needed. When the
autoload option is set off, the operator should manually unroll enough media before
starting to cut. When autoload is set to ask, then cutter will pause after that the pinch rollers
are put down. This gives the user the time to lower pinch roller pressure if necessary.
The default setting is ON. Tracking is not guaranteed when autoload is set to OFF.
Press the button, then use or to activate or deactivate the autoload
feature.
Press
,
to confirm or to cancel.
Autoload is default activated.
NOTE: Tracking is not guaranteed when autoload is set to OFF.
Front Margin:
The front margin is the amount of media the cutter returns after it measured the front edge
of the loaded media. It can be set between 10mm and 500mm.
Press the button, then use or to set to the desired value.
Press
,
to confirm or to cancel.
The default value is 24.6mm.
