S CLASS™ cutter User’s Manual
Contour Cutting 3-4
8. Press to confirm.
The cutter will make a circular movement while it measures the reflection of the media. It will
briefly display the measured values and display the message “put knife on black area.”
9. Use , , or to maneuver the knife on top of a black
area (approximately in the middle and slightly to the bottom right).
10. Press to confirm.
The cutter will make a circular movement while it measures the reflection of the marker
color. It will briefly display the measured values, then it will show a value that is
characteristic for this media color – marker color combination. Store this value for future
reference.
NOTE: An error message may appear if the sensor is not able to differentiate between black
and white. Make sure that the test has been performed correctly. If OPOS is not able to
sense the markers, one of the manual alignment methods (see 4.3.1.4.) must be used.
