S CLASS™ cutter User’s Manual
Contour Cutting 3-13
3.4 Automating Tasks with OPOS
OPOS allows the user to automate certain tasks, thus reducing user intervention and
production time. When cutting multiple graphics, the user only needs to maneuver the
OPOS sensor above the Origin marker of the first graphic; cutting subsequent graphics does
not require additional user input.
There are two multiple-job situations in which OPOS can be used:
When cutting multiple (copies of a) graphic(s) on the same media roll.
When cutting the same graphic on multiple media sheets.
Most automated tasks are organized from within the cutting software. However, when the
same graphic contour needs to be cut out, then the automatic tasks also involve some
manual manipulation.
Before using the automating features, note the amount of your cutter’s RAM. If the cutter’s
RAM is greater than the job’s file size, then the automating features may be used. If the
cutter’s RAM is less than the job’s file size, then the automating features may not be used.
3.4.1 Cutting multiple copies of a graphic on the same roll
If the same graphic design has been printed on a roll with equal distance between the
different graphics, then this feature can be used.
First, load the media and be sure the parameters of the OPOS markers are set correctly.
Cutting multiple copies of the same graphic on the same media roll:
1. Press .
The main menu will appear on screen.
2. Press
.
The configuration menus will appear on screen.
3. Press .
The general settings will appear on the screen.
4. Press .
The current value of the recut offset will appear on screen.
5. Use or to change the recut offset (the distance between the last cut
vector and the beginning of the first marker).
