Basic Operation 2-1
2 Basic Operation
2.1 Touch Screen
The 320x240-dot touch screen provides a unique interface system that provides detailed
cutter status information and offers a more flexible and powerful control of the cutter’s
configuration.
All screen and optional panel controls on the touch screen are easily formatted to allow
quick access to the most common cutter settings.
Next to the status messages and/or menu options displayed on the touch screen, you will
see button symbols that can be pressed to change menu items or to change the value for a
given submenu/parameter.
FIG 2-1
2-1 TOUCH SCREEN
There is also screen saving feature. After a certain amount of time the screen goes blank and
the model type of cutter appears and disappears in the middle of the touch screen.
Touching the screen once disables the screen saver.
FIG 2-2
2-2 SCREEN SAVER
WARNING
Each keystroke can initiate an internal test or movement of head or media.
Keep fingers and other body parts away from the cutting area.
There are hazardous moving parts.
